Longer Cycle Life: Offers up to 20 times longer cycle life and fiveimes longer float/calendar life than lead acid battery, helping tominimize replacement cost and reduce total cost of ownership.

Lighter Weight: About 40% of the weight of a comparable leadacid battery.A'drop in' replacement for lead acid batteries.

Higher Power: Delivers twice power of lead acid battery, evenhigh discharge rate, while maintaining high energy capacity.

Wider Temperature Range:-20C~60C.

Superior Safety: Lithium lron Phosphate chemistry eliminateshe risk of explosion or combustion due to high impact, overchargincor short circuit situation.

Increased Flexibility: Modular design enables deployment to four batteries in series and up to ten batteries in parallel.







Electrical Characteristics

Nominal Voltage

12.8V

Nominal Capacity

50Ah

Energy

640Wh

Internal Resistance

≤50mΩ

Cycle Life

≥3000 cycles @1C 100%DOD

Months Self Discharge

<3%

Efficiency of Charge

100% @0.5C

Efficiency of Discharge

96~99% @1C





Standard Charge

Charge voltage

14.4±0.2V

Charge mode

0.2C to 14.4V, then 14.4V,charge current to 0.02C (CC/CV)

Charge current

25A

Max Charge Current

50A

Charge cut-off voltage

14.6V±0.2V



Standard Discharge

Continuous Current

50A

Max. Pulse Current

150A(<5s)

Discharge Cut-off Voltage

10V



Environmental

Charge Temperature

0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity

Discharge Temperature

-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity

Storage Temperature

0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity

Water Dust Resistance

IP65







Mechanical

Cell & Method

32700  6Ah 4S9P or 3.2V 50Ah Prismatic cell

Plastic Case

ABS

Dimensions (mm./in.)

197x166x176mm

Weight (kg./lbs.)

7.0Kgs

Terminal

M8

LED display

     Optional

Bluetooth

     Optional
