RVs Battery

Inquire Now

Longer Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.

Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.

Higher Power: Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.

Wider Temperature Range: -20℃~60℃.

Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.

Increased Flexibility: Modular Design enables deployment of up to up to ten battery in parallel.

Model	YS-12V-100Ah	YS-12V-150Ah	YS-12V-200Ah
Nominal capacity	1280Wh	1920Wh	2560Wh
Operating voltage range	10.0V-14.6 V
Nominal voltage	12.8 V
Number of cycles	≥3000 @ 100% DOD
Charging characteristics	CC-CV
Charging voltage	14.4 - 14.6V
Maximum recommended charge current	50A	75A	100A
Maximum charge current	100A	150A	150A
Discharge current	100A	150A	150A
Maximum discharge current (≤5 sec.)	500A	500A	500A
BMS Battery Management System	Built-in Smart BMS,over charge/discharge protection/over load protection/short circuit protection/temperature protection and balance function
Monitoring	Bluetooth 4.0 with smartphone app
Application/ Interconnection	RVs/Motorhomes/Campering cars
Protection	IP56
Temperature range (discharge)	-20°C to +60°C
Temperature range (charge)	0°C to +45°C
Temperature range (storage)	0°C to +40°C
Terminal	M8	M8	M8
Warranty	3 year manufacturer's warranty
Weight	12.8kg/15Kg	17.5kg	25.0kg
Dimensions (L x W x H) in mm	L328W172H212mm±2mm L353W175H190mm±2mm L260W168H212mm±2mm	L485W172H240mm±2mm	L523W235H222mm±2mm L485W172H240mm±2mm
